Aluminum Composite Panel Manufacturer
Jiangyin ACP Industry Co., Ltd. — a one-stop aluminum composite panel supplier based in Jiangyin, China.
Jiangyin ACP Industry Co., Ltd. — a one-stop aluminum composite panel supplier based in Jiangyin, China.
ALUCOVERBOND is a professional manufacturer of aluminum composite panels (ACP), specialized in advanced materials for building, signage, transportation and industrial applications.
From standard PVDF cladding panels to fire-rated B1 & A2 mineral-core products, 2000mm ultra-wide formats, aluminium lattice-core panels and high-performance polyester-coated sheets, we offer a complete ACP range from one factory — with 36+ standard colors and full custom color service.
Our team knows the trade: most factory operators have been with us for over twenty years, which shows in the consistency of every batch we ship.
Explore our aluminum composite panel range and specifications, or send your project requirements for a quotation.
"No traders, no markup — talk to the people who make the panels."
From coil pre-treatment to lamination, every step happens under our own roof.
Aluminum coil arriving from the mill carries rolling lubricants and surface deposits. Our chemosynthesis line — using qualified industrial chemicals and advanced technology from Henkel, Germany — cleans these away and forms a dense honeycomb oxide film on the metal surface. This film is the strong bonding medium between paint and metal.
Our three-roller reversal precision coating machine applies coatings to chemically treated aluminum and stainless steel coils in a sealed, dustless environment — delivering solvent resistance, hardness, flexibility, glossiness and strong adhesion.
Under high temperature and pressure, metal sheets, PE core material and adhesive polyolefin film are firmly laminated into one panel with a guaranteed flat surface. Our peel strength tests above the quality benchmarks of imported panels.
Every production run is checked against our full test regime — appearance, coating, mechanical and weathering properties.
| Coating thickness | ≥ 25 μm, verified per batch |
|---|---|
| Pencil hardness | ≥ HB (typical result: H) |
| Boiling water resistance | 2 h, no change |
| Acid / alkali resistance | 5% HCl and 5% NaOH, 24 h, no change |
| Solvent resistance | 100 rubs, base coat not exposed |
|---|---|
| Salt spray resistance | 3000 h, grade 1 |
| Accelerated weathering | 4000 h, color difference ≤ 4.0 (typical: 1.24) |
| Peel strength (180°) | ≥ 7.0 N/mm (typical: 11.2 N/mm) |
No traders, no markup — talk to the people who make the panels.
